Cabling & Network Services

Network cabling is the backbone of your business. It’s what connects all of your systems together to help you do what you do best. Computer use and speeds have changed dramatically in the last decade. Traditional phone systems are being replaced by VOIP(voice over internet protocol) systems, which can give your business economic and functional efficiencies that did not exist several years ago. The right type of network cabling must be used to utilize all the new cost-saving technologies that are now available.

With years of experience at structured data cabling in the Dallas/Fort Worth area, Politon can help you design a solution to meet your current and future needs. If your business needs cabling for a new VoIP phone system or a traditional PBX, Politon has years of experience helping customers grow their business. Contact us today at 214-441-7173 to find out what our telecommunications professionals can do for your business.

Services Include:

  • Cabling Site SurveysCabling site surveys are essential to overcoming obstacles and allowing for the most accurate, cost-efficient quotes. Our data cabling professionals know what issues to look for and how to overcome them.
  • Demarc Extension ServicesA demark extension is how we take the phone/data services that the phone/data company has provided for your business from one area to another. Typically the demarc room is on the outside corner of the building (MPOE) and your data closet (MDF) may be located anywhere in the building. Politon can extend those data connections via fiber or copper depending on the connection type to your suite whether your in an office, strip center, high rise or warehouse.
  • Network Wiring TestingCopper and fiber cabling is the backbone of your IT systems. We test both fiber and copper networks.
  • Structured Cabling InstallationOur structured cabling services can plan, design and install whatever your cabling needs (Cat 5e, Cat 6, fiber, coax). Politon can maintain, troubleshoot or upgrade any size network from small retail locations to large million-square-foot warehouses.
  • Wi-Fi Network InstallationWi-Fi installations are usually determined by square footage of space and design. Each location is unique and will have a solution custom-designed for number, models, and locations of Wi-Fi access points.
  • IT Installation – Politon can be your Smart Hands tech resource for when your staff does not have either the reach or time to perform plug and play solutions for IT hardware to your business locations. We can replace your IT hardware locally in the Dallas/Fort Worth area or nationwide. We have performed services such as replacing or adding a network switch, firewall device, LTE router, desktop PC, printer, POS, EMV (CC machine), RAM, networked time clock, Wireless Access Points or UPS (battery backup).
  •

    Recent Cabling Installation Jobs

    Recently Completed Jobs

    See All

    Fort Worth, TX

    The main portion of this project was connecting the two office spaces through data cabling allowing for an extension of the network used. This was especially difficult because one office space was on the 6th floor and the other was on the 5th floor of the neighboring building. Proving to be an even harder challenge as the pipes between the building had been busted and required a bit of ingenuity to allow for proper functionality. Once we were able to move and connect the cabling to each building, it was discovered that inside the office space the old tenant had pulled the data cabling and rebuilt walls around them. In an effort to utilize the old cabling we had to dig out the old cabling and reconfigure them to the new floor plan. To allow for a more enjoyable work-life experience, we added new additions to the conference and training room. These included adding AV cables that connected the HDMI cables from the TVs to an HDMI plate below the TV, and a CAT-6 to HDMI extension data cable. This allowed employees easy access when connecting laptops to the screens during important presentations. We also revamped the entire data rack and installed all the data cabling for the wifi and installed wifi access points. With 140 total cables, our team was able to completely build an entirely new office space.

    Crossroads, TX

    We installed OM3 multi-mode fiber to two new cottages to bring internet connectivity as well as a connection to the networked fire panels. The customer was very pleased to add these two new buildings to their existing fiber ring around their campus. We essentially had to cut the existing ring and incorporate two new buildings into the ring by pulling fiber to them and back-feeding the connection from the far building to the return portion of the campus loop. All new fiber was certified and staged for their network administrator to come out and plug in his equipment.

    Dallas, TX

    H Betti Industries in Dallas, Texas, was having some problems with their access points. Politon worked with the IT Support team to identify four out of six access points that were not working. Fortunately, the IT Support team had shipped four replacements which we installed. At the end of the day, all six access points were working as expected.

    Plano, TX

    The COACH Store in Plano, Texas, needed three ATAs installed. This job included the following tasks: * Pulling a Cat 6 cable through the wall, over the suspended ceiling, and down to phone system * Terminating three pairs of cables on both ends with RJ11 connectors * Testing the lines for good quality

    Burleson, TX

    The Saddle Creek South location in Burleson, Texas, requested an Ethernet drop to a time clock outside the central office. We started running a cable from cabinet 9 which is mounted 35 feet up on a post. From there, we went across the girders and inside the 40-foot-high walls of the central office. After terminating and testing the cable, we mounted the time clock which worked perfectly.

    Burleson, TX

    The Saddle Creek South location in Burleson, Texas, contacted us to install two Ethernet drops in the guard shack. Fortunately, Politon had already run fiber to the guard shack and installed a switch, making the job easier. After finding a path from the switch to the guard's desk, we routed, terminated, and tested both cables. Everything worked properly.
